Description
Expand your workstation with this 3-Port MST Hub – DisplayPort to 3x HDMI Adapter, enabling support for up to three 4K 60Hz HDMI monitors from a single DisplayPort 1.4 output. Leveraging Multi-Stream Transport (MST) and DSC (Display Stream Compression), this USB-powered hub is ideal for multitasking, trading, digital signage, and professional applications. The integrated 1ft (30cm) cable offers flexible positioning, while plug-and-play functionality ensures quick setup. Compatible with Windows only, this high-performance adapter turns a single DP output into a full-featured triple-display solution.
Key Features
-
Triple HDMI Output – Connect up to 3 HDMI monitors from a single DisplayPort source
-
Supports 3 x 4K @ 60Hz – Stunning Ultra HD performance across all outputs
-
DisplayPort 1.4 + DSC + HBR3 Support – Efficient bandwidth usage for multi-monitor setups
-
MST Technology – True extended desktop support on Windows
-
1ft (30cm) Built-in Host Cable – Flexible positioning for desktops or tight setups
-
USB Powered – No bulky power brick required (USB-A to Micro-USB cable included)
-
Plug-and-Play – No drivers needed for most Windows systems
-
Compact & Durable – Professional-grade build, ideal for high-demand environments
Specifications
-
Input Connector: DisplayPort 1.4 (Male, via 1ft built-in cable)
-
Output Connectors: 3 × HDMI 2.0 (Female)
-
USB Power Connector: Micro-USB (USB-A to Micro-USB cable included)
-
Max Resolution Support:
-
3 x 3840x2160 @ 60Hz (when host supports DSC and HBR3)
-
2 x 4K + 1 x 1080p (with limited GPU bandwidth)
-
Single 8K @ 60Hz (if only one port is used)
-
-
Display Modes: Extended, Mirrored, Collage (via Windows Display Settings)
-
MST Support: Yes (Windows 10/11 only)
-
Audio Support: Yes (HDMI pass-through)
-
HDCP Support: Yes (HDCP 2.2)
-
Operating System Compatibility: Windows only (macOS does not support MST)
Product Dimensions / Weight
-
Hub Size: ~3.9 x 2.4 x 0.6 in (10 x 6 x 1.5 cm)
-
Built-in Cable Length: ~1ft (30cm)
-
Weight: ~5.1 oz (145 g)
Package Dimensions / Weight
-
Package Size: ~8.3 x 5.5 x 1.6 in (21 x 14 x 4 cm)
-
Shipping Weight: ~6.7 oz (190 g)
