Description
Upgrade your handheld radio’s performance with the Genuine Nagoya NA-701 Antenna, a compact yet powerful dual-band high-gain antenna. Professionally tuned for 144/430MHz frequencies, the NA-701 delivers exceptional signal strength and clarity for both VHF and UHF bands. Measuring just 8 inches, it offers the perfect balance between performance and portability, outperforming standard stock antennas and providing superior UHF efficiency. Each Nagoya antenna is individually tested and precision-tuned to ensure top-tier performance and durability. Compatible with Baofeng, BTECH, Kenwood, and other SMA-Female radios, this is the ideal upgrade for reliable long-range communication.
Features:
-
Certified Genuine: Authentic Nagoya NA-701 antenna, factory-tested for quality and performance.
-
Dual-Band Efficiency: Tuned for 136–174MHz (VHF) and 400–520MHz (UHF) frequencies.
-
Compact Design: 8-inch flexible whip offers enhanced performance with easy portability.
-
Superior UHF Performance: Optimized for UHF frequencies—more efficient than the NA-771.
-
Durable & Reliable: Built from high-quality materials to withstand outdoor and field use.
-
Enhanced Reception: Boosts weak signals and improves transmission range.
-
Universal Compatibility: Works with Baofeng, BTECH, Kenwood, and other SMA-Female radios.
-
Easy Installation: Simple screw-on connection; no adapters or tuning required.
Specification:
-
Model: Nagoya NA-701
-
Frequency Range: 136–174MHz (VHF), 400–520MHz (UHF)
-
Optimal Frequency Range: 140–150MHz, 420–450MHz
-
Wave: 1/4λ (144MHz), 1/4λ (430MHz)
-
Gain: 2dBi
-
Max Power: 10 Watts
-
VSWR: < 1.5:1
-
Impedance: 50 Ohm
-
Connector: SMA-Female
-
Length: 8.25 inches (21 cm)
-
Compatibility: Baofeng UV-82, UV-5R, BF-F8HP, BTECH UV-5X3, Kenwood TK Series, and other SMA-F radios
-
Note: Not compatible with UV-9R waterproof models
