Description
Capture high-precision thermal imaging on the go with the VEVOR Thermal Imaging Camera for Android and iOS devices. Featuring a powerful 256 x 192 IR resolution, this compact infrared imager delivers clear thermal visuals and smooth real-time performance with a 25Hz refresh rate. The built-in visible light camera and wide temperature detection range (-4°F to 1022°F) make it ideal for HVAC diagnostics, electrical inspections, home energy audits, and more. Compatible with both Android (Type-C) and iOS devices, it offers wireless connectivity, adjustable emissivity, and a rugged IP54-rated body built for field use.
Features
-
High IR Resolution: 256 × 192 pixel thermal sensor captures detailed infrared imagery.
-
Dual Platform Support: Works with Android (Type-C) and iOS devices via wireless connection.
-
Wide Temperature Range: Detects temperatures from -4°F to 1022°F (-20°C to 550°C).
-
Fast 25Hz Refresh Rate: Delivers smooth, real-time thermal imaging with minimal lag.
-
Built-in Visual Camera: 640 x 480 resolution for overlay and reference imaging.
-
Precision Adjustments: Adjustable emissivity (0.01–1.00) for accurate readings in varied materials.
-
Rugged & Portable: IP54-rated body with ABS, PC, and zinc alloy construction—ready for tough environments.
Specifications
-
Item Model Number: HT-W01
-
Thermal Imaging Resolution: 256 x 192 pixels
-
Visible Light Camera: 640 x 480 pixels
-
Temperature Detection Range: -4°F to 1022°F (-20°C to 550°C)
-
Thermal Sensitivity: 32.18°F / 0.1°C
-
Refresh Rate: 25Hz
-
Field of View: 56.0° × 42.0°
-
Focus Distance: 0.13 inch / 3.2 mm
-
Adjustable Emissivity: 0.01 - 1.00
-
Measurement Accuracy:
-
300°C–550°C: ±4%
-
-15°C–300°C: ±2°C or ±2%
-
-20°C–-15°C: ±4%
-
-
Interface Type: TYPE-C
-
Product Dimensions: 5.98 x 1.4 x 1.34 in / 152 x 35.6 x 34 mm
-
Net Weight: 0.55 lbs / 0.25 kg
-
Material: ABS + PC + Zinc Alloy
-
Operating Temp: 14°F to 122°F (-10°C to 50°C)
-
Storage Temp: -4°F to 140°F (-20°C to 60°C)
-
IP Rating: IP54
